Gabion mesh shearing machine
Mesh shearing machine (back view)
Hexagonal mesh shearing machine
Model |
ABE-JW-4*2500 |
ABE-JW-3*4350 |
|
Wire diameter |
4mm |
3mm |
|
Mesh shearing width |
2500mm |
4350mm |
|
Shearing strength |
450N/mm2 |
450N/mm2 |
|
Shearing angle |
1°30' |
1°30' |
|
Max. distance of backaguage |
550mm |
||
Stroke number per minute |
22 |
20 |
|
Blade length |
2600mm |
4400mm |
|
Height of working table above the floor |
800mm |
800mm |
|
Main motor |
Model |
Y132S-4 |
Y132S-4 |
Power |
5.5KW |
5.5KW |
|
Revolution |
1500r/min |
1500r/min |
|
Motor for backgauge |
Model |
Y80-6 |
Y80-6 |
Power |
0.55KW |
0.55KW |
|
Revolution |
910r/min |
910r/min |
|
Oil pump |
Model |
PLV-14 |
PLV-14 |
Flow |
14 ml/r |
14 ml/r |
|
Pressure |
21MPa |
21MPa |
|
Overall size |
Length |
3240mm |
5040mm |
Width |
1300mm |
1300mm |
|
Height |
1435mm |
1435mm |
|
Machine weight |
3200Kg |
4680Kg |
|
Contents of oil tank |
90L |
90L |
